Product datasheet

F002-Z-09-VP

PTFE vacuum wand for up to 6 inch (150 mm) wafers, normally open, Vespel tip


£239.00

$318.00    €318.00

Add to Cart

Please register or login to buy this product.

Complete vacuum wand including tip for wafer handling. PTFE body. Normally open push-button valve (press to release the wafer). Vacuum is automatically switched off when placed in stand 658 or 659. The tip can be rotated and locked in position. With Vespel tip for continuous use up to 288°C. Wand body and tip available separately. The vacuum tube connector allows push-on connection to any flexible tubing from 2.5 mm to 4 mm ID. The tube connector has a quick connection feature that allows wands to be interchanged rapidly.

  • Teflon (PTFE) provides excellent chemical resistance
  • Normally open push-button valve (press to release the wafer).
  • Gross weight including packaging: 70 g.


ModelF002-Z-09-VP
OperationNormally open push-button valve (press to release the wafer).
Length241 mm
Net weight35 g
